Smart N95 Respirator

Description

18301
Smart N95 Respirator

For premium protection and experience, please take care of your product.

1. Check the surface of the respirator filter regularly. Once apparent fouling is observed, please replace the filter timely to avoid reduction of the fresh air as the collected contaminants are accumulated.
2. Install the fan module and the filter cap according to the instruction manual before use. Proper installation can prevent air leakage, abnormal disassembly, and loss.
3. Maintain the fan module after use by wiping possible water droplets on the module surface; Proper maintenance can benefit the service life of the product.
4. This product has one size that fits the face contour of most people.
5. The product is sealed immediately after production. It may absorb ambient odor during transportation, which will disappear a few minutes after unpackaging. The safety of the product is certificated by IFDA tests.
6. For reduction of carbon emission and environmental protection, a power charging cable is NOT provided along with the product. A regular micro-USB cable is applicable.
7. Scan our QR code and keep in touch in order to keep updated with promotion information.

Product specification:

• Product name: N95 Respirator (General/Sport) w/Rechargeable Fan
• Product code: 18301
• Rated voltage : DC5V
• Rated power : 0.4w
• Battery capacity : 500mAh
• Battery duration : 5-10 hours
• Weight: 50.5g
• Module size : 80*38*20mm
• Executive standard : IEC 60601-1 :2005+A1:2012
• Effective date : One years

Indications:

• Filtration efficiency>95% for N95
• Shortness of breathing problems
• Healthy and comfortable breathing experience.
• Epidemic prevention barrier

Replacement of the Fan Module Filter

1. Use the filter replacement tool which is inside part of the fan module to open the filter cap.
2. Remove the filter cap and the white-colored air filter is exposed.
3. 3. Put a new filter into the module.
4. 4. Use both hands to push the filter cap to tighten the cap.

Replacement of the Respirator Filter

1. 1. Push the tail end of the fan module, pull the fan module upward and remove it!
2. Hold the inner and the outer clamping pieces with two hands, Separate the two clamping pieces apart
3. Take out inner damping pieces
4. Replace the used respirator filter with a new one operate the above procedures in a reversed order to complete the installation of the fan module.

Product Structure:

1. 1. Mask Holder buckle
2. Inner clamping piece
3. Respirator filter
4. Outer cover
5. Outer clamping piece

Table Of Size:

One size fits all faces in General and Sports Version.

Switch/Shift

1. 1. The switch button, located on the upper side of the product, has a power symbol.
2. Long press three seconds to start up, and then the green light is on. Short press during the runtime, the product can be cyclically adjusted for three stages.
3. 3. Long press to power off, then the light turns off after twinkling several times.
4. When the green light twinkles during the runtime, it indicates the battery is too low. The light twinkles 20 minutes before the battery runs out.

Charging Instruction

1. The charging port is located on the downside of the product, which is a Micro USB charging port. The charging voltage is 5V. The charging current is 1A/2A. Please do not use 9V/12V or other fast-chargers.
2. When charging, the red light is on. After a full charge, the red light turns green.
3. It takes about 2 hours for the product to be fully charged.
4. It is not recommended that use the product when charging.

   Materials: PP, PE, PC, Elastane, Nylon, Polyester.
